An ideal solution for remote private and public applications,
the Tricon Plank-Deck™ Bridge System delivers safe, fexible and
economical options for rapid bridge deployment. With minimal
equipment and manpower required, this precast concrete bridge
system can be erected and in use in one day. Once again, Tricon’s
customer-centric approach to solving on-site construction
challenges has delivered a proven winner in the feld.
The Tricon Plank-Deck™ Bridge System consists of standardized
precast concrete components; abutment/bent footings, riser
sections and plank-deck slabs. The plank-deck elements
incorporate the driving surface which means that no topping
or wearing surface is required after installation. With the
superstructure manufactured entirely of precast concrete, there is
no cast in place concrete required on site. All standardized elements
are sized to enable delivery to site in legal weight truckloads and
the entire structure to be constructed and erected with a medium-
sized track-hoe (Hyundai 380 or equivalent) and minimal personnel.
These attributes make the Tricon Plank-Deck™ Bridge System ideal
for remote locations and rapid deployment.
Key Benefits and Features
Flexible, Economical and Rapidly Deployable Short Span
»
Componentized precast concrete
system eliminating cast in place
concrete construction.
»
Standard stock abutment, bent and
deck components are combined to
ft each site condition.
»
System can be erected and in use in
one day.
»
Ideal for remote locations or
temporary emergency access.
»
Designed to handle total
inundation.
»
Can be designed to either AASHTO
LFD, LFRD, or customer-specifc
load rating criteria.
»
Plant-manufactured to the highest
D.O.T. quality control standards.
»
Durable, economical, low
maintenance precast concrete –
will not rust, rot or burn.
»
Will outlast most other building
materials, including wood
and steel – a sensible choice
for sustainable development.
»
Deck elements incorporate the
driving surface; no added topping
or wearing surface is required.
»
Unique componentized design
allows system to be dismantled,
moved and reused.
»
Bolt-on railing options are
available.
